Quick Details

  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: RUILONG, Ruilong
  • Model Number: water well drill pipe, Water well drill pipe
  • Type: Drill Pipe, Drill Pipe, Foriction welding
  • Machine Type: Drilling Tool, Drilling Tool
  • Certification: ISO 9000, API ISO9001
  • Material: Carbon Steel, High Manganese Steel
  • Processing Type: Forging, Forging
  • Use: Well Drilling, Well Drilling
  • Product name: Bao steel R780 Water Well Drill Pipe
  • PN: TS-00988

Packaging & Delivery

Packaging Details: Wooden case
Standard export package or as your requirement
Delivery Detail: Winthin 10 days after payment

drilling pipe

drilling pipe



Product Description

 Product Name:Geological Drill Rod

 Diameter         :42mm

 Length              :1000mm

Thread Type     :taper  thread

Production Technology: frication welding

Connection Form:         :BOX*PIN

Main Usage         : Coal Mining Exploration, Geological Exploration

water well drill pipe

No.

Specifications(mm)



Connection Type

Milling (mm)

Thread Connection (mm)

Hexagonal

connection

Limbers

(mm)

Dia.



Length

Big Dia.

Small Dia.

Thread Distance

Type

Size

DZG-189

42

500

29

29

6.35

--

20

One

32

DZG-21

42

1000

34.5

34.5

6.35

--

29

--

--

DZG-75

42

1000

34.5

30

4.233

--

15

one

30

DZG-187

42

1000

34

34

4.233

--

13

one

30

DZG-1997

42

1000

33.5

30

5.08

--

14

one

34





Bao steel R780 Water Well Drill Pipe

Product Description:

  •  1: OD: 89mm ( 3.5' inch) thread drill pipe
  •  2: Connection: 121mm
  •  3: Material:R780/E75/N80
  •  4: Length:  4.5meters or as your requirement
  •  5: Wall thickness:9.5mm/10mm
  •  6: Yield/Tensile strengthMin 517Mpa/Min 689Mpa
  •  7: Suitable for water well, geothermal well, gas well
  •  8: Safe drilling depth: Within 1,000 meters
  •  9: Tool joint:35CrMo/40Cr

Specification:

1.Drill pipe

Drill Pipe Diameter (inch)Thickness TypeSteel Pipe GradePipe Wall ThicknessConnection Tool Joint Diameter(mm)Thread Weight(kg)
1.6"EUDZ506.5Φ57 1:165.7
R7806.5
2"EU,IUDZ506.5Φ65, Φ681:167
N80,R7806.5
2 3/8"EU,IUE75,R7807Φ75, Φ78NC269.4
E75,G1057.11
2 7/8"EU,IUN80,R7809Φ95, Φ105NC3114.2
E75,G1059.11
3 1/2"EU,IUN80,R7809.5/10Φ121, Φ127NC3818.6
E75,G105 9.319

2.Tensile performances of API drill pipe:

Steel Grade

Yield Strength

Tensile Strength

Min(Mpa)

Max(Mpa)

Min(Mpa)

Max(Mpa)

E-75

517

724

100

689

R780

520

666

780

876

Drill Pipe pictures:



Packaging & Shipping







Company Information





FAQ

Q1:Are you a manufacture or a trade company?

Answer:Manufacture.

Q2:Do you have quality control system?

Answer: Yes,we check every production process and test pressure for each tool to make sure no problem.

Q3:How can I get a booklet and buy a product from you?

Answer:Very easy!Just leave me a message and tell me your requirements,let me know you are  interesting in our products.

I will talk with you for the detail soon.

Q4: Can you tell me your size and specification.

Answer:

1.Give me your drawing with detail requirements.

2.Give me the product no.After you checked our booklet.

3.Don’t forget to tell me the quantities,this is very important.

4.Give me your size and specification.

5.Your destination port.
